HEAT EXCHANGER MECHANICAL DESIGN AND DETAILING

HEAT EXCHANGER MECHANICAL DESIGN AND DETAILING

service 8
  • Design and Analysis of Heat exchanger ("U" Tube, Fixed Tube sheet with or without Thin/Thick expansion joints), Floating Head.
  • Design Code: ASME Section VIII, Div. - 1, TEMA & API 660 by using PV Elite software
  • Thermal design of shell & Tube heat exchangers
  • Mechanical calculation as per ASME Section VIII Div. 1, TEMA Standards etc
  • Fitness-for-service evaluations for heat exchangers to assure the structural integrity of equipment
  • Finite Element Analysis for heat exchangers and heat exchanger components
  • General arrangement drawing & detailed fabrication drawing
  • Material Selection- We can offer you proper materials in high temperature, or for very corrosive services.
  • Doing Local Load calculations for nozzles & supports as per WRC, PD5500, etc.
  • Re-rating of existing heat exchanger for a new set of design parameters.
  • Fatigue analysis to calculate the fatigue life of heat exchanger subjected to pressure cycles, temperature cycles and start up / shutdown cycles.
  • Detailed Material Take Off
